Description
It is mainly composed of clamp frame, mechanical mechanism, electrical control system, cable drum and other parts. 1. Clamp frame: The main part of the electric steel coil clamp is spliced by steel plate (high-quality low-alloy steel), and the cross-section is a box-shaped structure, which has good anti-bending and torsional performance, making the clamp lightweight. 2. Mechanical mechanism: adjust the opening size of the clamp hoisting range through the mechanical mechanism.
Features
- Clamp sleeve, round steel or steel billet.
- Electric rotation of 90 degrees, rotation speed of 3-4r/min.
- Clamp with mechanical automatic switch device.
- The motor is equipped with a frequency converter.
- The position of the stop device must be ensured during welding.
- This fixture adopts the lever principle and can achieve object clamping without external assistance. The clamping is reliable, the action is flexible, and the lifting is safe and reliable.
Technical Data
|
Specification (mm) |
Steel Coil Parameters (mm) |
Fixture Opening A |
Size(mm) |
||
|
B |
C |
D |
|||
|
8T |
ID：500 |
250-1900 |
1000 |
2700 |
2900 |
|
OD：2200 |
1000 |
2700 |
2900 |
||
|
15T |
ID：500 |
250-1900 |
1000 |
2700 |
2900 |
|
OD：2200 |
1000 |
2700 |
2900 |
||
|
30T |
ID：500 |
250-1900 |
1000 |
2700 |
2900 |
|
OD：2200 |
1000 |
2700 |
2900 |
||
Applications
Clamps are widely used in industries such as metallurgy, transportation, railways, ports, etc
