Description
F23 series adds 4 multi-function buttons, which can set different functions as required, so as to be applicable to a variety of different working scenarios.
Features
- Various voltages can be switched at will, and the voltage can be converted according to customer needs.
- Comfortable feel and reliable performance
- Equipped with high-performance antennas to effectively improve wireless signal performance
Technical Data
|
F23-A++ Transmitter parameters |
|
|
Shell |
Glass Fiber Reinforced Nylon |
|
Protection grade |
IP65 |
|
Frequency range |
VHF:310-331MHz |
|
Transmitted power |
<10dBm |
|
Emitter power supply |
2AA |
|
Safety code |
32 bit |
|
Temperature |
Normal |
|
Control distance |
100 meters |
|
Warranty |
12 months |
|
Size |
164*75*46 mm |
|
F23-A++ receiver parameters |
|
|
Shell |
Glass Fiber Reinforced Nylon |
|
Protection grade |
IP65 |
|
Frequency range |
VHF:310-331MHz |
|
Receiver sensitivity |
-110dBm |
|
Receiver power supply |
24V/36V/220V/380V AC |
|
Safety code |
32 bit |
|
Temperature |
Normal |
|
Out contector capacity |
8A sealed relay outout (with AC 250V/10A relays, 10A fuse) |
|
Cable length |
1.3m (Other length can be customized) |
|
Size |
168*166*93 mm |
Applications
The remote control is suitable for hoisting machinery, engineering machinery, construction machinery, loading/unloading machinery, lifts, truck cranes, winch equipment, lifting platforms, hydraulic and pneumatic equipment, fire-fighting equipment, railway bridges and tunnel construction and various human control is not and is not allowed. Wire-controlled electronic control equipment. It is used to enhance the safety and reliability of equipment, improve the working environment, reduce labor intensity and improve work efficiency.
Service
2. Providing customized product solutions based on different working conditions, temperature, type, voltage, etc.
2. Replacement of damaged components (non-human-induced) is provided during the warranty period.
2. Safety and Compliance Support: Ensure that their products comply with local and international safety and regulatory standards, and provide relevant documentation and support.
2. We will send professional Chinese crane installation team or find local crane installation team according to the product plan and customer demand, to ensure that the product can be used safely and effectively.
